IP68 rated washable 16mm stainless steel optical trackball Mouse

K-TEK-16-OTB
minimum order
1 set
Supply Ability
3000.0set / Month
Country of Origin
SHEN ZHEN AND HK
Quantity
Contact Now
add to cart

Model NO:K-TEK-16-OTB

Dimension: 42.9mm x 28.6mm

Description: IP68 dynamic rated washable 16mm stainless steel optical trackball MODULE with 800 DPI resolutions for fast and accurate cursor position with extremely smooth operation without any noise.

TECHNICAL SPECIFICATION

ITEM

SPECIFICATION

Mechanical Data

Ball diameter

16mm

Track ball lifespan

> 5 Mio revolutions

Actuation Force

1.0N to 3.0N

Dimension

16.0 mm (1’) diameter for ball, 42.90mm x 28.6mm (front panel)

Interface

PS2, USB are available, Y type cable with ports of PS2 and USB

Electrical

Power supply

5V DC+ 10%, keyboard interface

Protection level

IP65 (dynamic), NEMA3

EMC Standard

EN55022(B)

Power consuming

≤1.00W(dynamic)

≤0.2W(static)

Environmental

Operating temperature

-20ºC~+ 60º C

Storage temperature

- 30ºC~+ 70ºC

Operating RH

30~90%

Atmospheric pressure

60~106Kpa.

Reliable

Certificates

RoHS compliant, CE and FCC certified.

MTBF

>20000H

MTTR

< 30min

OS

DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/Win 7, Linux, Unix, Mac OSX

Packing Details

Each unit to a suitable brown inner box, suitable brown inner boxes to a standard export carton.
