Military silicone keyboard with a conventional handheld mouse
-MEETS MIL-STD-461G WITH EMC MIL-STD-810F
-ADJUSTABLE WHITE BACKLIGHT INCLUDED
-FN KEYS ON THE TOP LINE FOR EASY OPERATION
-TOP PANEL MOUNT WITH 4 SINKING HOLES
-MILITARY LEVEL
DESCRIPTION: 87 keys IP65 dynamic sealed & ruggedized silicone rubber military keyboard, 12 FN function keys (F1, F2...F11, F12) on
the top line for easy operation, integrated with a conventional handheld mouse with middle wheel, left/right buttons as well as a IPX6 rated
38mm mechanical trackball mouse with 400~1000DPI resolution for fast cursor moving, military PCB with carbon-on-gold key switch technology
with 1.5mm key stroke with extremely good tactile feeling for fast and accurate data input without any noise, with durable coating & antimicrobial
keyboard surface treatment withstand to most chemicals and liquids under harsh environment, FN+ CLEAN combination keys for easy cleaning
via locking/disable the entire keyboard without taking away the keyboard from PC, the electronics controller module is shielded and protected
by aluminum housing, with four sinking holes for panel mount to user's device. Adjustable white backlight included. Design to meet MIL-STD-461G
with EMC (Electro Magnetic Compatibility) & MIL-STD-810F (wide temperature, shock, vibration,humidity etc.)
DIMENSIONS: 465.0mm x 160.0mm (Front Panel)
MECHANICAL DATA | |
Key | 87 keys + 3 mouse keys |
Key top style | Protuberant rectangular keys with tactile feeling. |
Key Size | 12.5mm X 12.5mm for normal keys, 22.8mm x 12.5mm for enter key 68.4mm x 12.5mm for space bar key |
Key travel | 1.5mm±0.1mm |
Actuation Force | 1.5N±0.2N (pressure point ) |
Switch life | more than 5 million of operations. |
G.W. | 3.00KGs |
ELECTRICAL DATA | |
Supply Voltage | DC +5V±5% |
Current Rating | 50mA when backlight is off, 300mA with backlight on |
Meet MIL-STD-461G with EMC (Electro Magnetic Compatibility) etc.: | |
1 | CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads |
2 | CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads |
3 | CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads |
4 | CS106 Conducted Susceptibility, Transients, Power Leads |
5 | CS112 Electrostatic Discharge Susceptibility |
6 | CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection |
7 | CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation |
8 | CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads |
9 | RE101 25Hz -100kHz Radiated Emissions, Magnetic Field |
10 | RE102 10kHz - 18GHz Radiated Emissions, Electric Field |
11 | RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field |
12 | RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field |
MIL-STD-810F (wide temperature, shock, vibration, humidity). | |
Lifespan | > 5 years |
Switch Contact Material | Military PCB with carbon-on-gold key switch technology |
Interface | Aviation plug or USB |
Cable length | Standard 2.0m, customized length available. |
OS | All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed). |
ENVIRONMENTAL ADAPTABILITY | |
Operating temperature | -40℃ to +75℃ |
Storage temperature | -45℃ to +85℃ |
Saline mist | 96h, IEC60512-6 |
Damp heat test at +40℃ | 21 days, IEC 60512-6 |
Dry heat test at +85℃ | 10 days, IEC 60512-6 |
Humidity | 3%~95% |
Atmospheric pressure | 60-106Kpa |
RELIABILITY | |
RoHS compliant, CE and FCC certified, MIL-STD-461G (EMC, EMI, EMS, ESD) and MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity) | |
Protection Level | IP65 dynamic (front panel) |
Key Lifespan | >5 million actuations |
MTBF | >20000H |
MTTR | <30min |
APPLICATIONS | Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station etc. |
